Dynamic Source Imaging the Brain
CMU biomedical engineers make giant leap forward in neuroimaging
By Dan CarrollMedia Inquiries
- College of Engineering
Marking a major milestone on the path to meeting the objectives of the National Institutes of Health BRAIN initiative, research by Bin He advances high-density electroencephalography (EEG) as the future paradigm for dynamic functional neuroimaging.
The NIH Brain Research through Advancing Innovative Neurotechnologies (BRAIN) Initiative motivates researchers to "produce a revolutionary new dynamic picture of the brain that, for the first time, shows how individual cells and complex neural circuits interact in both time and space." An ideal technique for functional human brain imaging — one of the initiative’s top priorities — would depict brain activity with high temporal resolution, high spatial resolution and wide spatial coverage.
He, head of Carnegie Mellon University’s Department of Biomedical Engineering (BME), has made a major leap forward for the field of functional neuroimaging. An NIH-funded study lasting several years and examining dozens of patients with epilepsy has produced a novel source imaging technology that uses high-density EEG recordings to map underlying brain networks. Published in Nature Communications, this research is a big step toward establishing the ability to dynamically image human brain function and dysfunction. This could provide important insight into both where and how underlying information-processing occurs.
EEG has long been one of the most effective functional methods available for human brain mapping. It takes readings in a matter of milliseconds; however, the technology still struggles with determining the spatial extent of activity within the brain. The approach proposed by He and his team can accurately estimate for the first time the size and scope of active areas within the brain using high-density EEG, as well as interactions between regions that are functionally related. Their findings were validated using clinical recordings made at the Mayo Clinic, analyzing a total of 1,027 EEG spikes and 86 seizures recorded from 36 patients.
The team’s method, termed the fast spatio-temporal iteratively reweighted edge sparsity (FAST-IRES) technique, uses machine learning to objectively estimate signal sources and activity as they vary over time. Unlike prior imaging techniques, it needs no ad hoc algorithm or human intervention for determining source extent and requires only minimal, intuitive input from physicians.
FAST-IRES could have a major impact on the research and treatment of various neurological and mental disorders like Alzheimer’s disease, Parkinson’s disease, stroke, chronic pain and even depression. However, this method is uniquely and most immediately impactful for those suffering from drug-resistant epilepsy.
Around one percent of the global population suffers from epilepsy, and roughly one-third of cases are drug-resistant, requiring surgical intervention. Yet until now, no current non-invasive imaging modality has had the spatial specificity to accurately determine the epileptogenic zone (EZ), which represents the minimum amount of tissue that must be removed to halt seizures.
"By analyzing epilepsy networks with our proposed FAST-IRES framework, we have demonstrated that the EZ can be determined objectively and noninvasively with high precision from scalp high density EEG recordings," wrote He and his co-authors.
Their findings were validated against readings from conventional invasive intracranial recordings and surgical outcomes from each patient, proving FAST-IRES’ effectiveness.
The study also marks one of the first times high-density EEG has been used to study epileptic seizures. The more powerful imaging technology, packing more than double the electrodes generally used in a clinical setting, is now available to patients treated at the Mayo Clinic. He believes that within the next five years, the FAST-IRES methodology will begin to impact the way we understand a number of neurological disorders.
"This work demonstrates that EEG source imaging may become the non-invasive high-spatial, high-temporal resolution paradigm for human brain imaging technology, an important goal of the BRAIN Initiative," said He, who served as a member of the NIH BRAIN Multi-Council Working Group from 2015-2019.
He’s research may be life-changing for those suffering from epilepsy and could benefit researchers and physicians across the field of neurology, neurosurgery and human neuroscience. This work brings the NIH and the scientific community one step closer to achieving a revolutionary new dynamic picture of the brain.
The work is a multi-year collaboration with Gregory Worrell’s team at Mayo Clinic, Rochester. Other collaborators on the paper included first author Abbas Sohrabpour, a BME postdoctoral associate; co-authors Zhengxiang Cai and Shuai Ye, BME Ph.D. students in He’s lab; and clinical co-authors Worrell and Benjamin Brinkmann of the Mayo Clinic.
This work was supported in part by the National Institute of Neurological Disorders and Stroke, National Institute of Biomedical Imaging and Bioengineering, National Institute of Mental Health, and National Center for Complementary and Integrative Health.
